Kilargo Medium Duty Low Profile Threshold Plate - Clear Anodised

Create a compact low-profile sealing surface beneath doors to help limit rain, draught and smoke penetration.

This 1000mm threshold plate measures 25mm wide x 5mm high and is manufactured from silver anodised aluminium. It is designed for use with Kilargo door bottom seals and can be fixed using the supplied stainless steel screws and plugs or builder's adhesive.

Key features

• 1000mm length
• 25mm wide x 5mm high profile
• Silver anodised aluminium construction
• Stainless steel fixing screws and plugs supplied
• Complies with AS1428 Part 1 for design for access and mobility
• Fire tested to AS1530 Part 4 in accordance with AS1905 Part 1

Common uses

• Use with Kilargo door bottom seals
• Helping reduce rain, draught and smoke penetration beneath doors
• Accessible doorways including wheelchair traffic areas

Item Code

IS4110-1000CA

Content and Downloads

• IS4110 Kilargo Fact Sheet
• IS4110 Fitting Instructions
